Aluminum & Vinyl Windows, Patio Doors, Storefront & Doors, Curtain Wall, Sunshades
1505 Series Casement, Awning & Hopper
What sets our windows and doors apart is how effortlessly they integrate with any space - enhancing the environment whether they're open or closed. Designed to balance refined aesthetics with reliable performance and long-lasting strength, our systems come in a wide range of styles and configurations, giving you the freedom to bring virtually any deisgn vision to life.
Extrusions
AT-17 w/AT-12 Vent
AT-17 w/AT-12 Vent
AT-17 w/AT-12 Vent
AT-4 w/AT-12 Vent
AT-17 w/AT-12 Vent
AT-17 w/AT-12 Vent
AT-17 w/AT-35 Vent
AT-4 w/AT-35 Vent
Optional Subsill, Comp Channels & F-Clip
Subsill
Head Comp
Head Comp
Head Comp
Head Comp
Head Comp
F-Clip
Head Comp
F-Clip
Finishes
Marlin offers anodized, painted and powder-coat finishes in any available specification or color.
Because custom-painted windows require extended lead times for color selection, sample submittal, and production as well as additional cost for setup and minimum order quantities, Marlin recommends this as an option for larger projects that allow for added time.
Marlin inventories the two most popular anodized finishes - clear and dark bronze for all of our window series. We do have black anodized in stock for certain styles. Please see below for sample colors: clear, bronze and black anodized. Our dark bronze is very, very dark!
T.I.E. Technology
Extruded aluminum remains a top choice for windows due to its strength, durability, and low maintenance. Marlin Windows uses high-quality aluminum alloys specifically engineered for demanding window applications, along with extruded glass stops that enhance structural performance and allow for consistent anodized finishes.
Our thermally improved systems feature an integrated polyurethane thermal barrier within the extrusion. This design significantly reduces heat transfer and helps control condensation, resulting in improved energy efficiency and long-term performance.
Hardware
Roto Hardware
Project-In Handle
Push-Out Handle
For project-out vent. Mounted at vent bottom, it allows for approximately 10" of opening. The double arm design also helps achieve corner pull-in and vent stability.
High-pressure die-cast zinc case, crank handle and knob. Hardened steel worm and gear arm.
Push-Out Handle
Project-In Handle
Push-Out Handle
Bronzecraft standard push/pull & locking handle for casement and project-out windows.
Project-In Handle
Project-In Handle
Project-In Handle
Bronzecraft push/pull locking handle for operation of in-swing vents.
Locking Handle
Locking Handle
Project-In Handle
Allows for special key to lock or unlock.
Butt Hinge
Locking Handle
4-Bar Hinge
Cast bronze alloy exposed hinge is standard on casements with roto operators or push out hardware.
4-Bar Hinge
Locking Handle
4-Bar Hinge
Stainless steel self-balancing hinge. Standard for awnings, hoppers and inswing casements. Friction adjustment holds windows open at any position.
Friction Arm
Custodial Lock
Custodial Lock
Marlin's projected windows are balanced with either one or two heavy duty four bar friction hinges. Friction hinges are stainless steel and include a positive stop and an adjustable friction shoe.
Custodial Lock
Custodial Lock
Custodial Lock
Allows for control of vent operation. Requires a special key to lock or unlock.
Pole End
Pole End Handle
Pole End Handle
For opening or closing clerestory or high-mounted windows.
Pole End Handle
Pole End Handle
Pole End Handle
For clerestory or high-mounted project-In vents
